EnGenius ECW270 Cloud Managed Wi-Fi 6 4x4 Outdoor Access Point with IP68 Rating

The EnGenius ECW270 is a Cloud Managed Wi-Fi 6 4x4 Outdoor Access Point designed for harsh environments, offering dual concurrent 802.11ax support. With an IP68-rated weatherproof and dustproof housing, it provides reliable connectivity with up to 2,400 Mbps in the 5 GHz band and 1,200 Mbps in the 2.4 GHz band. It supports mesh wireless, ensuring seamless setup and self-healing networks, and can be managed remotely via the EnGenius Cloud App.

Key Features:

• High-Performance Wi-Fi 6:

  • Dual concurrent 802.11ax with backward compatibility for 802.11ac/a/b/g/n devices
  • Supports up to 2,400 Mbps in the 5 GHz band and 1,200 Mbps in the 2.4 GHz band

• Rugged Design:

  • IP68-rated weatherproof and dustproof housing withstands harsh environments
  • Four detachable 5 dBi high-gain 2.4 GHz antennas and four detachable 7 dBi high-gain 5 GHz antennas

• Advanced Connectivity:

  • 1 x 2.5 Giga PoE+ compatible port for greater throughput
  • Power over Ethernet (802.3 at/bt) for flexible installation over 100 meters (328 feet)

• Efficient Management:

  • Zero-touch provisioning, centralized cloud management, and visualized monitoring
  • Cloud manage an unlimited number of APs from anywhere with the EnGenius Cloud App

Technical Specifications:

• Standards:

  • IEEE 802.11ax on 2.4 GHz and 5 GHz
  • Backward compatible with 802.11a/b/g/n/ac

• Antenna:

  • 4 x 2.4 GHz: 5 dBi (External Omni-Directional)
  • 4 x 5 GHz: 7 dBi (External Omni-Directional)

• Physical Interfaces:

  • 1 x GE Port
  • 1 x 2.5 GE Port (PoE+)

• Power Source:

  • Power-over-Ethernet: 802.3at/bt Input
  • Active Ethernet (PoE)

• Maximum Power Consumption:

  • 46W

• Operating Frequency:

  • Dual-Radio Concurrent 2.4 GHz & 5 GHz

• Radio Chains:

  • 4 × 4:4

• Data Rates:

  • Up to 2,400 Mbps on 5 GHz
  • Up to 1,200 Mbps on 2.4 GHz

• Environmental Specifications:

  • Operating Temperature: -4ºF to 149ºF (-20ºC to 65ºC)
  • Storage Temperature: -40ºF to 176ºF (-40ºC to 80ºC)
  • Humidity: 90% or less (non-condensing)
  • IP Rating: IP68

Package Includes:

• 1 ECW270 Cloud Managed Outdoor Access Point
• 2 Mounting Brackets
• 1 Wall-Mount Screw Set
• 4 2.4 GHz 5dBi Detachable Antennas
• 4 5 GHz 7dBi Detachable Antennas
• 1 Quick Installation Guide

The EnGenius ECW270 is ideal for providing high-performance, reliable wireless connectivity in outdoor and harsh environments, with robust management capabilities via the EnGenius Cloud App.
