Ubiquiti AF-5 Full-Duplex Point-to-Point Gigabit Radio

The mid-band model, AF-5, features the popular mid-band frequencies, which are freely used in many parts of the world. AF-5(US) Features: Max. Power Consumption 40W Power Supply 50V, 1.2A PoE...
Vendor: Ubiquiti
SKU: AF-5
Availability: In Stock
$964.00
$964.00
Subtotal: $964.00
Ubiquiti AF-5 Full-Duplex Point-to-Point Gigabit Radio

Ubiquiti AF-5 Full-Duplex Point-to-Point Gigabit Radio

$964.00

Ubiquiti AF-5 Full-Duplex Point-to-Point Gigabit Radio

$964.00
The mid-band model, AF-5, features the popular mid-band frequencies, which are freely used in many parts of the world.

AF-5(US) Features:
  • Max. Power Consumption 40W
  • Power Supply 50V, 1.2A PoE GigE Adapter (Included)
  • Power Method Passive Power over Ethernet
  • Supported Voltage Range +42 to +58VDC, -48VDC
  • Automatic Transmit Power Control (ATPC) Yes
  • Certifications CE, FCC, IC
  • Mounting Pole Mount Kit (Included)
  • Wind Loading 863 N @ 200 km/hr (194 lbf @ 125 mph)
  • Wind Survivability 200 km/hr (125 mph)
  • Operating Temperature -40 to 55° C (-40 to 131°F)
(12) Status LEDs:
  • Data Port Link/Activity
  • Data Port Speed
  • Management Port Link/Activity
  • Management Port Speed
  • GPS Synchronization
  • Master/Slave
  • Link Status
  • Modulation Mode 0.25x to 4x, 6x, 8x, 10x (Unlabeled), Overload
  • Remote and Local Displays (Calibrated Signal Strength)

Operating Frequency:
  • FCC 15.247, 15.407, IC RSS-210: 5470 - 5600 MHz, 5650 - 5850 MHz
  • ETSI EN 301 893, EN 302 502: 5470 - 5875 MHz
  • Other Regions: 5470 - 5950 MHz

Interface:
  • Data Port (1) 10/100/1000 Ethernet Port
  • Management Port (1) 10/100 Ethernet Port
  • Auxiliary Port (1) RJ-12, Alignment Tone Port

System:
  • Maximum Throughput 1.2+ Gbps
  • Maximum Range 100+ km (Dependent on Regulatory Region)
  • Packets per Second 1+ Million
  • Encryption 128-Bit AES
  • Uplink/Downlink Ratio 50% Fixed
